Kerosene Burner

Kerosene Burner
0.4 mm thick plated tin sheet container dia 75 x 55 mm height fitted with container lid locked with four aluminium wick holder dia 6.3 x 42 mm height. Cover with ebonite insulator and aluminium spacer to lock the container lid and chimney holder inside dia 45 mm x 5 mm height.MS sheet plated with centre 20 mm dia seam hole attached with inner chimney dia 20 mm inside x 56 mm height. Fitted with 0.4 mm thick plated cap. Outer chimney dia 45 mm x 56 mm height MS sheet 0.63 mm thick plated fitted with chimney holder. Both chimney at crossing points holes dia 1.5 distance 6.5 x 5.6 mm. Overall Burner height 140 mm.
                                                                                                                          Quantity 01
